Diffusers Services for Industrial Projects
Basic Description
Sagiant Piping Industries manufactures and supplies air diffusers for HVAC, cleanroom and industrial ventilation — square and round ceiling diffusers, linear slot and bar diffusers, swirl/twist diffusers, jet nozzle diffusers and perforated-face diffusers — in extruded aluminium, powder-coated steel and stainless steel 304/316. Diffusers are built to SMACNA, AMCA 210 / 500-D, ASHRAE and Eurovent practice with selectable throw, drop, neck size and air pattern, supplied with opposed-blade dampers, plenum boxes and equalising grids, AMCA-rated airflow/pressure performance and full project inspection documentation.
Diffuser types, materials, sizes and air-performance reference data
Air diffusers for HVAC, cleanroom and industrial ventilation. Sagiant Piping Industries / SPI Steel keeps diffuser types, construction materials, sizes, standards and performance data on one page for HVAC consultants, contractors and project QA teams.
Technical Specification
| Parameter | Specification |
|---|---|
| Product Type | Square, round, linear slot, swirl, jet nozzle & perforated-face diffusers |
| Material | Extruded aluminium 6063, aluminium sheet, GI / CRCA, SS 304 / 316 |
| Air Pattern | 1-, 2-, 3- and 4-way; adjustable / fixed core; swirl for high induction |
| Mounting | Surface, lay-in (T-bar), flush, exposed or concealed frame |
| Accessories | Opposed-blade damper (OBD), plenum box, equalising grid, side spigot |
| Finish | Powder coated (any RAL), anodized, mill or stainless finish |
| Performance | AMCA-rated throw, drop, NC level & pressure drop (AMCA 500-D) |
| Documentation | GA drawing, selection sheet, finish/coating record, dispatch list |
Construction Materials
| Material | Grade / Spec | Typical Use | Finish |
|---|---|---|---|
| Extruded aluminium | 6063-T5 | Face, frame, blades & bars | Powder coated / anodized |
| Aluminium sheet | 1100 / 3003 | Cones, back pan, plenum | Powder coated / mill |
| Galvanized steel (GI) | IS 277 / ASTM A653, Z180–Z275 | Plenum box, frame, blades | Pre-galvanized / powder coated |
| Cold-rolled steel (CRCA) | IS 513 / ASTM A1008 | Frames, damper blades | Powder coated |
| Stainless steel | 304 / 316 (ASTM A240) | Cleanroom, kitchen, corrosive areas | 2B / brushed (No.4) |
Diffuser Types & Configurations
| Type | Air Pattern | Typical Application |
|---|---|---|
| Square ceiling diffuser | 1/2/3/4-way | Offices, commercial false ceilings |
| Round / circular diffuser | Radial 360° | High-ceiling, architectural spaces |
| Linear slot diffuser | 1–8 slots, adjustable pattern | Perimeter, continuous runs, facades |
| Linear bar grille diffuser | Fixed 0° / 15° | Sills, floors, long architectural lines |
| Swirl / twist diffuser | High-induction radial | High ceilings, variable-air-volume rooms |
| Jet nozzle diffuser | Long-throw spot | Auditoriums, atriums, factories |
| Perforated-face diffuser | Multi-cone, low-turbulence | Cleanrooms, hospitals, labs |
Standards & Specifications
| Scope | Applicable Standards |
|---|---|
| Air performance & rating | AMCA 210 / 500-D, AMCA 511 certified ratings |
| Duct & sheet construction | SMACNA HVAC Duct Construction Standards |
| Design & ventilation | ASHRAE Handbook, ISHRAE, Eurovent |
| Material | ASTM A240 (SS), A653 (GI), A1008 (CRCA), aluminium 6063 / 3003 |
| Finish / coating | Powder coat, ASTM B117 salt-spray, anodizing AA-M12C22A41 |
Testing, Inspection & Documentation
| Test / Document | Detail |
|---|---|
| Airflow / pressure | AMCA 500-D test; throw, drop, NC & pressure-drop selection data |
| Finish | Coating thickness (DFT), adhesion, ASTM B117 salt-spray |
| Dimensional | Neck size, face size, slot / blade pitch, squareness |
| Material | EN 10204 2.2 / 3.1 mill certificate on request |
| Inspection | Sample approval, GA drawing sign-off, dispatch checklist |
Applications & Industries Served
Available Forms, Sizes & Range
Diffusers are jointed for continuous architectural runs; share ceiling type, neck size, airflow (CMH/CFM) and throw for exact selection.
| Item | Size Range | Wall / Thickness / Rating | Standard |
|---|---|---|---|
| Square / round diffuser | Neck 100–600 mm (face to 900 mm) | 0.8–1.5 mm sheet / extrusion | SMACNA / AMCA |
| Linear slot diffuser | 1–8 slots, length to 3000 mm/section | Extruded aluminium | SMACNA / Eurovent |
| Plenum box | To suit neck + spigot 150–400 mm dia | 0.8–1.0 mm GI | SMACNA |
Frequently Asked Questions
Which materials are available for diffusers?
Extruded aluminium 6063 and aluminium sheet are standard; GI/CRCA powder-coated and stainless steel 304/316 are available for hygienic, kitchen or corrosive areas.
Can diffusers be supplied with dampers and plenum boxes?
Yes — opposed-blade dampers (OBD), insulated plenum boxes, equalising grids and side spigots are supplied as matched assemblies.
Do you provide AMCA-rated performance data?
Selection is based on AMCA 210 / 500-D test data covering throw, drop, NC level and pressure drop for each neck size.
What finishes can be provided?
Powder coating in any RAL shade, anodized aluminium, mill finish, or stainless 2B/brushed finish.
What sizes are available?
Neck sizes from 100 mm to 600 mm with face sizes to 900 mm; linear diffusers up to 3000 mm per section, jointed for continuous runs.
